Data teknis
Elbow 90° Female-Female (F.F) berbahan Stainless Steel 304 berkualitas tinggi
Sangat ideal untuk kebutuhan sistem instalasi air, minyak, gas, kimia ringan, maupun aplikasi industri bertekanan yang membutuhkan ketahanan korosi ekstra
Bahan Tahan Karat & Durabel: Terbuat dari Stainless Steel 304 yang sangat tahan terhadap korosi, asam ringan, dan suhu tinggi
Koneksi F.F (Female-Female): Ulir dalam presisi di kedua ujungnya untuk kemudahan pemasangan sambungan siku 90°
Standar Ulir Presisi: Menggunakan tipe ulir BSPT yang standar, rapat, dan minim risiko kebocoran
Kuat & Tahan Tekanan: Konstruksi solid cocok untuk sistem perpipaan industri maupun rumah tangga
Jenis Fitting: Elbow 90° F.F (Female - Female) Threaded
Ukuran (Size): 1/8 inch
Tipe Ulir (Thread): BSPT
Material: Stainless Steel 304 (SS304)
Kondisi: 100% Baru
Catatan Pembelian:
Pastikan ukuran pipa/fitting Anda sesuai (1/8") sebelum melakukan pemesanan
Disarankan menggunakan seal tape / thread sealant pada bagian drat saat pemasangan agar koneksi semakin kedap dan bebas bocor
Stok siap kirim!
Katalog SKU
| Diameter | Nominal Size (inch) | Standard | Valve Type | Thread Size | Panjang (mm) | Schedule / Class | Class / Rating | Pitch (mm) | Tipe Drat | Grade | Pressure Rating | Facing | Material | Thickness (mm) | Size (inch) | Connection Type | Finish / Coating | SKU | Stok | Harga |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 9.7 | 1/8" | BSPT | N/A | 1/8" | 22 | N/A | CLAS150 | 0.907 | BSPT | ASTM A351 CF8 | PN16 | N/A | SS304 | 2 | 1/8" | THREADED | N/A | 9.7 - 1/8"inch - BSPT | 100 | Rp 16.400 |
